DMX512/1990 signal input

12 the power switch circuit

DMX control characteristics of the loop: 0-126 = OFF, 127-255 = ON

Power switch device: the bidirectional thyristor

Each circuit working status indicator light

Maximum load 5 a, every road no.12 total load is not more than 16 a

Insurance tube fuse overcurrent protection

The built-in 8 program, can choose speed

DMX signal input connector: XLR - D3M

DMX signal is directly output connector: XLR - D3F

19 "standard rack installation specifications

Power input: AC230V 50 hz/AC120V 60 hz

Dimension: 480 mmx146mmx74mm

Weight: 4.0 KG
